E-MBPP-DG Series Melt-Blown Polypropylene Microfiber Graded Density Filter Cartridges – Deep Groove
Endoer E-MBPP-DG series melt-blown polypropylene (PP) microfiber graded density cartridges provide economical performance for micronic retention of particulate in high-purity fluid filtration applications.
Deep grooved OD great...
Endoer E-MBPP-DG series melt-blown polypropylene (PP) microfiber graded density cartridges provide economical performance for micronic retention of particulate in high-purity fluid filtration applications.
Deep grooved OD greatly expands the external filtering surface. Precision manufacturing provides consistent product quality and performance. Design rated for efficiency of up to 80%.
Available in all common ratings and adaptation styles. Polypropylene's inherent inertness provides excellent resistance to chemicals.
Features
- Durable and inert polypropylene media & end adaptations
- Controlled fine porosity & absolute performance delivers excellent retention & capacity
- Component materials comply with US FDA and EU regulations for safe use with food products and potable water
- No glues, resins, or chemical additives used
- End adaptations are thermally bonded for strength and integrity
Applications
- Food products & ingredients; bottled water
- RO prefiltration
- Process water; wastewater
- Fine chemicals
Product Quality
- Manufactured within an ISO 9001:2015 certified quality management system.
- Certificate of Quality available upon request for each product lot.
Materials of Construction
| Media: | Polypropylene |
| End Caps: | Polypropylene |
| Seal Options: | Silicone, EPDM , NBR, FKM, E-FKM, Polyfoam |
Dimensions
| Diameter: | 66mm (2.6"), 115mm (4.5") |
| Lengths: | 5”,10”, 20”, 30”, 40” |
Operating Conditions
| Operating Temperature: | 60°C (140°F) max. |
| Operating dP (max.): | 3.5 bar (50 psi) @ 20°C (68°F) 1.2 bar (18 psi) @ 60°C (140°F) |
| Change-Out dP: | 2.6 bar (38 psi) @ 20°C (68°F) |
Clean Pressure Drop
Ordering Information
